Geprc Dolphin Caddx Vista 153mm GEP-20A-F4 AIO Toothpick

Introduction:

Dolphin HD is an upgraded version of dolphin 4inch, which is equipped with the latest CADDX VISTA HD Digital System.It has powerful flight performance and HD

FPV picture quality, so that you can experience the fantastic feeling of flying.

The weight is 160g (without battery), 153mm (motor to motor) , It bring powerful 1507 motor with HQ 4×4.3×3 V1S propeller, sufficient power and ensure efficiency. (4S-650 ~ 850mAh recommended)

Flight control with powerful GEP-20A-F4 AIO, integrated board F4 FC, ESC continuous current reaches 20A, stable and high-performance computing STM32F411 chip with MPU6000 gyroscope to ensure flight stability and very smooth feeling. Firmware is GEPRCF411, built-in Betaflight OSD, integrated LC filter. The flight controller has a silicone grommet,and the optimized PID has a significant noise reduction effect.

The Dolphin had been redesigned through professional assembled and debugged by GEPRC team. This mini Quad has excellent flight performance.

Features:

Ultra-light 4 inch toothpick frame, 3K carbon fiber bottom structure, True X frame design, split structure

High-Quality TPU 3D printed canopy with exquisite design

166g weight(without battery), ultra light weight, Enjoying fast and Furious flying

Equipped with Caddx Vista HD Digital System, the picture quality can reach 720p

The flight controller uses STM32F411 with MPU6000 gyroscope to work, and BLheli_S 20A ESC, flexibleand smooth flight

1507 3200KV motor with HQ4x4.3×3 V1S , Fantastic and efficient power extremely matching

The PID is meticulouslytestedby the GEPRC pilot team, it can fly as long as press BIND button with your Radio transmitter right on your hand

Specifications:

Brand:GEPRC

Item:Dolphin HD

Flight Controller:GEP-20A-F4 AIO

Camera: Caddx Vista HD Digital System

Motor to motor:153mm

Propeller:HQ4x4.3×3 V1S(4 pairs)

Antenna:RG137 5.8g RHCP

Motor:1507 3200KV

Weight:160g without battery

Receiver:Without Receiver(PNP)/Frsky R-XSR / Frsky XM+ / TBS NanoRX

Frame: GEPRC GEP-DX4

Carbon:Full 3K carbon fiber

Motor to motor: 153mm

Bottom plate: 2mm

Top plate: 2mm

Arms plate: 4mm

Flight Controller: GEP-20A-F4 AIO

MCU: STM32F411

Gyro:MPU6000

OSD:BetaFlight OSD w/ AT7456E chip

Firmware target: GEPRCF411

ESC: 20A * 4 BLHeli_S (Dshot/Multishot/OneShot) support 2~4S LiPo

VTX: 5.8GHz (48 Channel IRC Tramp,PIT/25/100/200mW)

Include:

1x Dolphin HD FPV Drone BNF/PNP

4x HQ 4×4.3×3 V1S (pairs)

1x Battery pad

2x Battery strap 15*120

1x M8 wrench

1x 1.5mm L screwdriver

2x antenna tubes
