1 pcs Servo 60kg High Torque DS5160

1X 60kg baja servo DS5160 SSG HV Digital Servo for 1/5 Redcat HPI Baja 5B SS RC Car compatible SAVOX-0236 LOSI XL 5T

Note: 1. The best use voltage is 7.4v.

It is recommended to use 2s battery for power supply (6v-8.4v)

2. The working angle of the servo is 180 degree or 270 degree (PWM: 500us-2500us)

Some remote controls can only output 1000-2000, it is recommended to buy 270 degree.

Package contains:

1 pieces of DS5160 Digital Metal Robotic Servo

​1 pieces of 18T servo arm

one set of screw(see the picture)

Or

1 pieces of DS5160 Digital Metal Robotic Servo

​1 pieces of 18T metal servo horn disk

one set of screw(see the picture)

Size:65*30*48(servo)

Weight:162g

Wire length:320mm

Speed: 0.17sec/60 degree at(6v)

0.15sec/60 degree at(7.4v)

0.13sec/60 degree at(8.4v)

Torque: 58kg.cm.at(6v)
65kg.cm.at(7.4v)

70kg.cm.at(8.4v)

Voltage: 6v-8.4v

Dead Zoon setting:3 Microseconds

Features:

- Durable Metal Gear
- Dual Ball Bearing
- Programmable Digital Amplifier with Mosft Drive
- Bottom Side Axial Mount Hole
- Original factory product
- Less Noise
-Contains: Long Holder Aluminum & Short Holder Aluminum & Circle Holder-18T & Circle Holder -Orientation Angle:maximum 180 or 270 deg

-Mechanical Angle :360 deg

(Plug/Output wheel/Radio control system compatible with Futaba JR Hitec)
