1pc Hobbywing Platinum 80A 3-6S Lipo BEC Brushless ESC

Description:

Scale: 1/10th, Brushless, Sensored

Cont./maximum Current: 160A/1200A

Input: 2-3S LiPo/4-9 Cell NiMH

BEC Output: Swich Mode: 6V/7.4V,4A

Input Wires: Black-12AWG-200mm*2

Output Wires: Black-12AWG-200mm*3

Input Connectors: No

Output Connecotors: No

Size: 25.0x25.0x10.0mm

Voltage Range: 5-7.4V

Powered by: Powered by BEC

SET Button on ESC: Not Supported

LED Program Box: Not Supported

LCD Program Box: Supported

WiFi Module: Supported

Program Port: Separate Program Port

Firmware Upgrade: Supported

Size: 37.5x30.9x31.6mm(w/Fan & Fan Shroud)

Weight: 95g(w/ Wires)

Applications:Motors: SL BL Motors / SD BL Motors

Vehicles: 1/10th Touring Car & Buggy & Drift Car & F1; 1/8th,1/10th Rock Crawler

KV Rating/T Count: 2S LiPo/6S NiMH: (Touring Car) T≥3.5T, (Buggy) T≥4.5T.

S LiPo/9S NiMH: (Touring Car) T≥6.5T, (Buggy) T≥8.5T.

Feature:

Excellent Motor Speed Governing

High-performance 32-bit processor with a prossesing frequency of 72MHz combined with

advanced algorithm optimizes the speed governing. Together with the adjustable governor

parameters it will guarantee every pilot a precise and efficient control experience.

High Voltage Built-in BEC

The built-in switch mode BEC with an adjustable voltage range from 5V to 8V, a continuous current of over 10A

and maximum current of 25A can supply enough power for your HV servos to operate at their maximum.

DEO Technology

The DEO (Driving Efficiency Optimization or so-called “Active Freewheeling”)

technology implemented in the ESC has multiple advantages.

A very Rapid response to throttle change.

Higher driving efficiency, longer flight time.

Lower ESC temperature and a much more reliable operation during flight.

Other Features

A separate program port for connecting programmer on this ESC allows user to

Program ESC,

Check flight data include minimum voltage, maximum temperature, standardized RPM and

speed curve (in Heli Governing Store mode) of the flight parameters recorded by the ESC,

Upgrade ESC firmware with a mutifunction LCD program box or a WiFi Module & our

Apple/Android phone App.

Four Brake Modes

This Platinum 80A V4 ESC has “Brake Disabled, Normal Brake, Proportional

Brake and Reverse Brake” four brake modes. The brake amount is adjustable in

normal brake mode; in proportional brake mode, the brake force will be

automatically selected based on the position of radio throttle stick; in reverse

brake mode, the motor rotation can be changed via a spare transmitter channel.

Package Included:

1x Hobbywing 80A V4 Brushless ESC
