$104.00
Specification: Brand name:Aomway Item name:700TVL FPV camera Pixel size: 5.00um X 7.40um Picture elements:976 (H)*496(V) FOV:170 degree Resolution: 700TVL Sensor: 1/3” CMOS Lens: 2.1mm/170degree wide angle Sensitivity:10.8(V/Lux.sec) Scanning System:2:1 Interlace S/N Ration:More than 45db Signal type: PAL AV output: 1Vp_p...
Specification:
Brand name:Aomway
Item name:700TVL FPV camera
Pixel size: 5.00um X 7.40um
Picture elements:976 (H)*496(V)
FOV:170 degree
Resolution: 700TVL
Sensor: 1/3” CMOS
Lens: 2.1mm/170degree wide angle
Sensitivity:10.8(V/Lux.sec)
Scanning System:2:1 Interlace
S/N Ration:More than 45db
Signal type: PAL
AV output: 1Vp_p 75ohm
Gain Control:Auto
White Balance:Auto
Work voltage: 3.6-5.5V DC
Weight: 12g
Dimensions:22*20mm
AV output: 1Vp_p 75ohm
Current: 120MA
Port: JST 1.25*5p JST port for Aomway mini 200mw or 600mw telemetry devices
Mol 2.54*5p for common devices
Feature:
With 1/3'' CMOS sensor
Performance rivals CCD. Nice quality low cost.
Super lightweight,ultra-low power consumption,suitable for RC multicopter
Package Included:
1 X 700TVL camera
1 X Cable
