DIATONE TAYCAN MX-C Frame Kit

MXC TAYCAN-Frame Kit Specification

SKU: MX C3 Taycan rack DT-FK19-MXC3-TAYCAN

Wheelbase: 158mm

Weight: 175g

Paddle size: 3 inch

Top plate: 2mm

Base plate: 2.5mm

Voltage (Recommendation): 4-6S

Flight control mounting hole : 20mm (M2) /30.5mm (M3)

Motor mounting hole position: 12mm

Camera pitch: 19mm, DJI sky end (20mm), compatible with 4K dual camera

MXC TAYCAN PNP Version：4S/6S

Camera: RUNCAM NANO2

Antenna: FOXEER Lolipop 3

VTX: MAMBA TX400 400mW

FC: MAMBA F405MINI MK3

ESC:

MAMBA F25MK2 /25A 4S ESC Dshot 600/

MAMBA F35 /35A 6S ESC Dshot 600

MOTOR: MAMBA Racing MB1408 4000KV/2800KV
