Hobbyporter WT8 2.4Ghz 6CH Transmitter Radio

Specification:(Transmitter)

Brand: Hobbyporter

Model: WT8

Frequency: 2.4Ghz

Frequency Hopping: Latest FHSS(64 points,3.6ms)

Channels: 6 channels

Resolution: 4096

Transmission:less than 100mw (20dbm)

Distance: >1000m (depends on actual situation)

Working Voltage:4.2-6v(AAA1.5v*4)

Working current: 100-150mA

Size:162*110*62MM

Color: Graffiti/Flame/Camouflage Color

Application:Helicopter,fixed wing, multi rotor,robot,car,boat

Specification:(Receiver)

Model: WT8S

Frequency: 2.4Ghz

Frequency Hopping: latest FHSS(64 points, 3.6ms)

Channels: 8 channels

Resolution: 4096

Working voltage:3.8-6v

Working current: 70mA

Protocol: compatible with Sbus,ppm

Size:17*11*2mm

Weight: 1.2g

Application:helicopter,fixed wing,multi rotor,robot,car

Nor/Rev set up:

Remarks: every channel Nor/Rev will be sound and LED indicated

Set up Steps:

Turn On: short press the power switch and keep lowest stick

Enter set up mode:long press Ch5/6 button simultaneously for 10s

Throttle reverse set up:keep the throttle stick at center and lower the stick to reverse the throttle once

Aileron, Elevator,Rudder. Move the stick to desired reverse channel

Nor/Rev Ch5/6. Long press the desire reverse channel for 1s

Cancel Nor/Rev set up, Long press the Ch5/6 for 3s

Communication Protocol:

Sbus/ppm selectable: Led flash rapidly when bind switch is pressed, LED keep solid light on when binding succeed within 30s is Sbus. If Led flash slowly when binding succeed within 30s is ppm

Receiver signal indication: Normal Sbus signal Led keep solid light on, Normal ppm signal Led flash once every 10s, Led off when no signal is detected.

Set up steps:

Turn on the radio and press binding switch, enter pairing mode when Led flash rapidly

Turn on the radio, Long press the binding switch by 3s until Blue Led flash slowly to hear a sound "Beep"then release the button. Blue Led flash rapidly to enter the pairing mode

Binding succeeded when the Led flash from rapidly to solid light on. Reboot the receiver. Press binding switch to complete the pairing

Receiver Antenna:

Keep antenna upright or it will lower the range of reception

Keep both antenna in 90 degree

Carbon fibre and metal components of the model will harmful to the reception of the receiver.Under this circumstances, the best antenna position should be keeping away from them and put correct angle of the antenna to obtain better reception

Negative: Negative to ground

Positive: Connect to 5v power

S signal: Sbus/ppm output signal
